China wholesale Single Acting Cylinder - Hydraulic Cylinder for Special Projects (GCD Series) – Canete Detail:

Product Description

Compact structure, nice appearance;

Alloy steel forging, corrosion resistance;

Equipped piston with buffer valve, prevent impact effectively;

Automatically pressure relief at stroke end, smooth performance, safe and reliable;

Overall thread connect cylinder button, cap and body, high strength;

Support ring, guide ring and seal are all imported;

Double acting version for fast retraction and construction efficiency.



Technical Parameters

Model	Push/Pull （T)	Stroke （mm）	Working Pressure (Mpa）	Bore Diameter （mm）	Plunger Diameter （mm）	Size（mm）			Weight （kg）
						Min. Length	Width	Height
KET-GCD-50-250	50/25	250	50	140	100	485	210	270	110
KET-GCD-50-500		500				735			160
KET-GCD-50-700		700				935			199
KET-GCD-50-1000		1000				1235			257
KET-GCD-100-250	100/50	250	50	180	120	581	240	320	162
KET-GCD-100-500		500				831			214
KET-GCD-100-700		700				1031			266
KET-GCD-100-1000		1000				1331			338
KET-GCD-100-1200		1200				1531			398
KET-GCD-100-1500		1500				1831			473
KET-GCD-200-250	200/100	250	50	240	160	640	310	400	306
KET-GCD-200-250		500				890			454
KET-GCD-200-700		700				1090			544
KET-GCD-200-1000		1000				1390			680
KET-GCD-200-1200		1200				1590			762
KET-GCD-200-1500		1500				1890			966
KET-GCD-200-2000		2000				2390			1216
KET-GCD-200-2500		2500				2890			1250
KET-GCD-300-250	300/150	250	50	300	200	689	370	480	508
KET-GCD-300-500		500				939			632
KET-GCD-300-700		700				1139			744
KET-GCD-300-1000		1000				1439			908
KET-GCD-300-1200		1200				1639			1016
KET-GCD-300-1500		1500				1939			1398
KET-GCD-300-2000		2000				2439			1580
KET-GCD-300-2500		2500				2939			2323
KET-GCD-400-500	400/200	500	50	320	220	955	420	520	780
KET-GCD-400-700		700				1155			1000
KET-GCD-400-1000		1000				1455			1220
KET-GCD-400-1200		1200				1655			1374
KET-GCD-500-250	500/250	250	50	360	250	715	460	560	726
KET-GCD-500-500		500				965			1034
KET-GCD-500-700		700				1165			1206
KET-GCD-500-1000		1000				1465			1482
KET-GCD-500-1200		1200				1665			1656
KET-GCD-500-1500		1500				1965			1888
KET-GCD-500-2000		2000				2465			2346
KET-GCD-500-2500		2500				2965			2803
KET-GCD-600-250	600/300	250	50	400	280	715	510	620	1214
KET-GCD-600-500		500				965			1547
KET-GCD-600-700		700				1165			1813
KET-GCD-600-1000		1000				1465			2212
KET-GCD-600-1500		1500				1965			2887
KET-GCD-600-2000		2000				2465			3552
KET-GCD-800-500	800/400	500	50	450	300	965	600	710	2090
		1000				1465			2906
KET-GCD-800-1000



<!–

–>

---





---
